Kategori
Marka
Stok Kodu
4LV230-H
Stok Durumu
Stok Var
Havale
1.324.999,20 TL
(%2,00 havale indirimi)
Standart Paket: Egzoz dirseği (L-tip), Egzoz çıkışı, Alternator 12V/130A, B25 Panel, VC10 Tekne kontrol sistemi, Hidrolik dümen, Mekanik mors kolu sensorü, Esnek takozlar, Genleşme tankı.
Configuration In-line, 4-stroke, vertical, water-cooled diesel engine Max. output at crankshaft* 169 kW@3800 rpm [230 mhp@3800 rpm] No. of cylinders 4 cylinder Displacement 2.755 L [168 cu in] Bore x stroke 92 mm x 103.6 mm [3.6 in x 4 in] Aspiration Turbocharged & intercooled Combustion system Direct injection, Denso common rail system Starting system Electric starting 12V – 2 kW Engine management Electronic Cooling system Fresh water cooling by centrifugal fresh water pump Seawater cooling by rubber impeller seawater pump Alternator Denso 12V - 130A Lubrication system Enclosed, forced lubricating system Engine lube oil specifications API class: CD or higher, SAE grade: 15W-40 Direction of rotation at crankshaft Counterclockwise (CCW) viewed from stern Dry weight without gear 334 kg [736 lbs] Engine dimensions† L x W x H 1151 x 755 x 772 mm Emission compliance EU: RCD 2, BSO II, ^ EMC US: EPA Tier 3, EPA-C Flywheel housing size Borg Warner / SAE #7 Controls Mechanical (optional - VC20 system)
Teknik veri: /dosya/4LV230-250.pdf
STOK VE TESLİMAT İÇİN LÜTFEN İLETİŞİME GEÇİNİZ.
Configuration In-line, 4-stroke, vertical, water-cooled diesel engine Max. output at crankshaft* 169 kW@3800 rpm [230 mhp@3800 rpm] No. of cylinders 4 cylinder Displacement 2.755 L [168 cu in] Bore x stroke 92 mm x 103.6 mm [3.6 in x 4 in] Aspiration Turbocharged & intercooled Combustion system Direct injection, Denso common rail system Starting system Electric starting 12V – 2 kW Engine management Electronic Cooling system Fresh water cooling by centrifugal fresh water pump Seawater cooling by rubber impeller seawater pump Alternator Denso 12V - 130A Lubrication system Enclosed, forced lubricating system Engine lube oil specifications API class: CD or higher, SAE grade: 15W-40 Direction of rotation at crankshaft Counterclockwise (CCW) viewed from stern Dry weight without gear 334 kg [736 lbs] Engine dimensions† L x W x H 1151 x 755 x 772 mm Emission compliance EU: RCD 2, BSO II, ^ EMC US: EPA Tier 3, EPA-C Flywheel housing size Borg Warner / SAE #7 Controls Mechanical (optional - VC20 system)
Teknik veri: /dosya/4LV230-250.pdf
STOK VE TESLİMAT İÇİN LÜTFEN İLETİŞİME GEÇİNİZ.
